| System | ||
|---|---|---|
| Main Processor | Embedded processor | |
| Operating System | Embedded linux | |
| Audio and Video | ||
| IP Camera Input | 16+2 channels, each channel up to 6MP | |
| Two-Way Talk | Reuse audio in/out, RCA | |
| Display | ||
| Interface | 1 HDMI; 1 VGA | |
| Resolution | 1920 × 1080, 1280 × 1024, 1280 × 720 | |
| Multi-Screen Display | When IP extension mode not enabled: 1/4/8/9/16 When IP extension mode enabled: 1/4/8/9/16 | |
| OSD | Camera title; Time; Video loss; Camera lock; Motion detection; Recording | |
| Recording | ||
| Compression | AI Coding/H.265+/H.265/H.264+/H.264 | |
| Resolution | 1080N; 720p; 960H; D1; HD1; BCIF; CIF; QCIF | |
| Record Rate | Main Stream: the 1st channel 1080N/720p (1 fps–25/30 fps), others 1080N/720p (1 fps–15 fps); 960H/D1/HD1/BCIF/CIF/QCIF (1 fps–25/30 fps) Sub stream: CIF/QCIF (1 fps–7 fps) | |
| Bit Rate | 32 kbps–4096 kbps per channel | |
| Record Mode | Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop | |
| Record Interval | 1 min–60 min (default: 60 min), Pre-record: 1 sec–30 sec, Post-record: 10 sec–300 sec | |
| Video Detection And Alarm | ||
| Trigger Event | Recording; PTZ; Tour; Video Push; Email; FTP; Snapshot; Buzzer and Screen Tips | |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18) | |
